Allen-Bradley 2094-AC09-M02

Allen-Bradley 2094-AC09-M02

Allen-Bradley 2094-AC09-M02 Module, Integrated Axis, 230V AC, 3.4 kW Inverter, 6 kW Converter



hot selling



I year warranty



Best choice and best discounts



Contact us:alice@cn2014.com





  • Brand :

    Allen-Bradley
  • Part number :

    2094-AC09-M02
  • Payment :

    bank transfer, T/T,PayPal, Alibaba,Alipay
  • Product Origin :

    U.S.A.
  • Color :

    New And Original
  • Lead Time :

    In Stock

The 2094-AC09-M02 is a 200 Volt class Integrated Axis Module from the Kinetix 6000 Motion control system. This IAM module operates at an input voltage of 230 Volts AC, 3-Phase. It delivers a continuous output current to bus of 19 Amperes and continuous output power to bus of 6 Kilowatts. This drive supports common-bus follower with DC input voltage of 275-375 Volts DC.



The Allen-Bradley 2094-AC09-M02 is an IAM (Integrated Axis Module) with a safe speed monitor from the Allen-Bradley Kinetix 6000 series. It is a part of the Bulletin 2094 that are made for driving servo motors. This module belongs to the 200 Volts class of IAMs and it has a power rating of 6 kW. The 2094-AC09-M02 servo drive module is a digital drive component engineered by Allen-Bradley which monitors the position of a servo motor and generates a control signal for the same motor. In this way, this IAM controls the position, current, and velocity of multiple axes on industrial machines.



This Kinetix 6000 module has an AC input voltage range of 195 and 264 Volts at a frequency of 50 to 60 Hertz. It also has a DC input voltage possibility rated at 325 Volts DC. The 2094-AC09-M02’s shipping weight is 2.31 kilograms (5.1 pounds). To work properly in the Kinetix 6000 servo drive system, this integrated axis module must be coupled with one control module. The unit provides the safe-speed and safe-off functionalities that are very important for sophisticated machines to achieve the highest possible protection level. The 2094-AC09-M02 implements the SERCOS interface and the EtherNet/IP interface. The short-circuit current rating for the 2094-AC09-M02 is 200,000 Amps symmetrical. The memory in the unit has 20 years of data retention. It is capable of saving several configuration settings for the unit. The module features 230 Volts rated digital input and output interfaces and it supports connection to a host PC and a PLC controller. The output frequency of this axis module is 0 to 400 Hertz.



The 2094-AC09-M02 is an Integrated Axis Module (IAM) that is part of the Kinetix 6000 multi-axis servo drive. This multi-axis drive operates at a nominal input voltage of 230 Volts AC, 3-Phase with applicable input voltage range of 195-264 Volts AC, 3-Phase. This drive also supports operating as a common-bus follower with a voltage range of 275-375 Volts DC. The 2094-AC09-M02 delivers a continuous output current of 19 Amperes and continuous output power to bus of 6 Kilowatts.



For installation, the 2094-AC09-M02 is installed onto a power rail. Compatible power rails are 2094-PRS1, 2094-PRS2, 2094-PRS3, 2094-PRS4, 2094-PRS5, 2094-PRS6, 2094-PRS7, and 2094-PRS8 Slim Power rails - or 2094-PR1, 2094-PR2, 2094-PR4, 2094-PR6, and 2094-PR8 Power Rails.



The 2094-AC09-M02 supports Serial Realtime Communication System (SERCOS) protocol. It uses Fiber optic media connected in linear or ring topology to build a network of 1 or more IAMs. This IAM is provided with a seven-segment display which is used to indicate the operational status of the drive, event, and fault codes.



The 2094-AC09-M02 through the SERCOS interface can be connected directly to a ControlLogix controller that is installed with a SERCOS interface module.



The 2094-AC09-M02 has a power dissipation of 14 Watts @ 20% utilization; 20 Watts @ 40% utilization; 28 Watts @ 60% utilization; 36 Watts @ 80% utilization, and 46 Watts @ 100% utilization. When mounting this module, minimum clearance requirements are 50.8 millimeters (2.0 inches) top and bottom clearance, while side clearances are not necessary.
